CAR-20

Kuzma MC cartridges.

Data about products  are informative - for current version of technical data or manuals consult us.

Kuzma CAR cartridges are made to our specifications by a Japanese company with over 50 years experience in this field. The same approach, with regard to design and manufacture of cartridges housings is used as in other Kuzma products. A combination of brass and aluminium parts made by us gives rigid and inert support to the  signal generator, allowing the diamond tip to extract musical information from the record grooves without distortion.

For CAR cartridges 5 years extended warranty do not apply!



Specifications

Type Moving Coil
Cartridge housing aluminium/brass
Coil Wire STD Copper
Cantilever Material Aluminium
Stylus Synthetic Elliptical
Frequency Response 10 Hz - 33 kHz
Output Voltage (3.54 cm/1 kHz) 0.3 mV
Channel Balance (1 kHz) <1 dB
Channel Separation (1 kHz) >23 dB
Tracking Force 2.0 g
Compliance 8 x 10-6 cm/dyne
Trackability >70 μm/2.0 g
Internal Impedance 4 Ω
Load Impedance <100 Ω
Net Weight 17 g
